2-DOF Azimuth Thruster

Project Name: Empirical Modeling of 2-DOF Azimuth Thruster based on Signal Compression Method
Research Necessity:
- Existing underwater robots use multiple fixed thrusters, resulting in large volume and weight. To solve this, a 2-DOF Gimbal Mechanism capable of changing direction with a single thruster is needed.
- Underwater propulsion systems have complex hydrodynamic characteristics, making Analytical Modeling extremely difficult.
- Traditional frequency response experiments struggle to obtain high-frequency data, limiting the establishment of precise control models.
Core Objective: Derive an Empirical Mathematical Model covering the entire frequency range (low to high) through actual hardware experiments.

2-DOF Gimbal Mechanism Design:
- Designed a structure that freely controls the thrust direction using two servo motors (Yaw, Pitch).
- Manufactured and mounted a Counter Mass with the same shape and mass (1.35kg) as the servo motor to resolve center of gravity imbalance.
Underwater Waterproofing Solution:
- Applied O-rings to all fastening parts and used Rotary Seals on rotating shafts to block fluid ingress.
- Applied Cable Glands to prevent water intrusion into motor wires.
Electronic Component Configuration:
- Thruster: Maxon MI60 (Max Thrust 7kgf, Rated 24V).
- Controller: NI Compact RIO 9049 (Real-time Controller).
- Sensor: 6-axis F/T sensor (ROBOTUS RFT80-6A01) placed at the top to measure reaction force and moment.

Signal Compression Method (SCM) Application:
- Principle: Based on the theory that applying an impulse signal to a system reveals the entire frequency response, but uses an Equivalent Impulse Signal instead of an actual impulse to avoid damaging the physical system.
- Algorithm Implementation:
  1. Generate time-domain test signal (Frequency band and time delay parameters set to a=450, b=2100).
  2. Convert to frequency domain via FFT (Fast Fourier Transform) and apply phase delay filter.
  3. Compress and restore the system output to time-domain impulse response via IFFT (Inverse Fourier Transform).
- Advantage: Separates linear and non-linear components in a system containing non-linearities, allowing effective estimation of only linear system parameters.

Experimental Data Processing:
- Performed a total of 180 experiments varying thruster output (PWM 55%~95%) and rotation axes (1-axis, 2-axis).
- Performed coordinate transformation and position compensation using Homogeneous Transformation Matrix since Sensor Frame and Moving Frame positions differ.
Transfer Function Derivation:
- Analyzed the slope of the measured Bode Plot to determine the system Order.
- Calculated coefficients (k, a, b, c, d, e, g) minimizing error between experimental data (Raw Data) and model using MATLAB's fmincon optimization technique via Curve Fitting.

Model Accuracy Verification:
- Cross-correlation Coefficient analysis between derived transfer function model and actual experimental data:
  - Mz,1 (Z-axis Moment): 0.83 (Very High Accuracy).
  - Fy,1 (Y-axis Force): 0.75.
  - Fx,1 (X-axis Force): 0.60.
Error Analysis & Engineering Insight:
- Gimbal Inertia: The low correlation coefficient for Fx,1 is due to the large inertia of the gimbal structure causing non-linear overshoot and vibration during rotation.
- Gravity & Buoyancy Disturbance: Identified that model tracking performance for Fz dropped slightly due to the combined effects of gravity and buoyancy.
Conclusion: Confirmed that the proposed 2-axis propulsion system contributes to the Compact Design of underwater robots, and suggested that lightweight gimbal design is essential for future control performance improvement.

Research Paper (PDF): [Download/View PDF](/assets/신호압축법을 이용한 2자유도 애지머스 추진기의 실증적 모델.pdf)
RISS Research Information: View on RISS↗
